規格 |
|
產品編號 |
|
偏距 |
|
分布圓 |
|
螺栓孔 |
10*2.5 |
|
10 0250 02 |
|
-37.6 |
|
Φ136.5 |
|
6-Φ10.5 |
10*6 |
|
10 0600 13 |
|
-30.5 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 15 |
|
-30 |
|
Φ114.3 |
|
5-Φ14.3 |
10*6 |
|
10 0600 23 |
|
-10 |
|
Φ101.6 |
|
4-Φ13 |
10*6 |
|
10 0600 24 |
|
0 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 26 |
|
8.4 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 27 |
|
-5.5 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 30 |
|
0 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 37 |
|
-5.5 |
|
Φ114.3 |
|
5-Φ14.3 |
10*6 |
|
10 0600 38 |
|
-5.5 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 40 |
|
-5.5 |
|
Φ101.6 |
|
4-Φ12.5 |
10*6 |
|
10 0600 42 |
|
-5.5 |
|
Φ100 |
|
4-Φ13.5 |
10*6 |
|
10 0600 47 |
|
-16.5 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 49 |
|
38.1 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 53 |
|
-31 |
|
Φ114.3 |
|
5-Φ12 |
10*6 |
|
10 0600 55 |
|
25.4 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10 0600 58 |
|
30.5 |
|
Φ114.3 |
|
5-Φ14.3 |
10*6 |
|
10 0600 61 |
|
-4.8 |
|
Φ101.6 |
|
4-Φ14.3 |
10*6 |
|
10060068 |
|
8 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 06 |
|
3.7 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 14 |
|
-57.6 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 15 |
|
-28.5 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 16 |
|
12.7 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 17 |
|
-19.05 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 24 |
|
-36.8 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 27 |
|
8 |
|
Φ114.3 |
|
5-Φ12 |
10*7 |
|
10 0700 28 |
|
12.7 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 29 |
|
0 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 31 |
|
-12.7 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 32 |
|
15.7 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 33 |
|
-19 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 34 |
|
-3 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 37 |
|
-38 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 39 |
|
-14 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 40 |
|
12.2 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 44 |
|
-4.3 |
|
Φ114.3 |
|
5-Φ12 |
10*7 |
|
10 0700 45 |
|
-31.8 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 46 |
|
-19 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 55 |
|
21.2 |
|
Φ101.6 |
|
4-Φ15 |
10*7 |
|
10 0700 63 |
|
-35.6 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 64 |
|
19.1 |
|
Φ130 |
|
4-Φ15 |
10*7 |
|
10 0700 67 |
|
-2.4 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 69 |
|
0 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 70 |
|
25.4 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 71 |
|
-18.5 |
|
Φ114.3 |
|
5-Φ12.7 |
10*7 |
|
10 0700 74 |
|
47.8 |
|
Φ114.3 |
|
5-Φ12.7 |
10*7 |
|
10 0700 80 |
|
35.6 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 82 |
|
-25.4 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 87 |
|
3.7 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 90 |
|
-31.2 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 0700 92 |
|
44.5 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 93 |
|
-47 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 0700 96 |
|
-18 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 070 100 |
|
-7.1 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 070 104 |
|
8.9 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 070 105 |
|
-34.9 |
|
Φ114.3 |
|
5-Φ14.3 |
10*7 |
|
10 070 106 |
|
-25.4 |
|
Φ101.6 |
|
4-Φ15 |
10*7 |
|
10 070 107 |
|
-12.7 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10 070 112 |
|
-30.5 |
|
Φ101.6 |
|
4-Φ14.3 |
10*7 |
|
10070114 |
|
-2 |
|
Φ114.3 |
|
5-Φ13.5 |
10*7 |
|
10070118 |
|
13 |
|
Φ114.3 |
|
5-Φ13.5 |
10*8 |
|
10 0800 13 |
|
-9 |
|
Φ114.3 |
|
5-Φ13.5 |
10*8.5 |
|
10 0850 04 |
|
-50.8 |
|
Φ114.3 |
|
5-Φ14.3 |
10*8.5 |
|
10 0850 09 |
|
42.2 |
|
Φ114.3 |
|
5-Φ12 |
10*8.5 |
|
10 0850 15 |
|
-33.9 |
|
Φ140 |
|
5-Φ18.5 |
10*8.5 |
|
10 0850 16 |
|
-51 |
|
Φ101.6 |
|
4-Φ15 |
10*8.5 |
|
10 0850 17 |
|
-2.5 |
|
Φ101.6 |
|
4-Φ14.3 |
10*8.5 |
|
10 0850 18 |
|
7.6 |
|
Φ101.6 |
|
4-Φ14.3 |
10*8.5 |
|
10 0850 19 |
|
-15 |
|
Φ114.3 |
|
5-Φ13.5 |
10*8.5 |
|
10 0850 20 |
|
-27 |
|
Φ101.6 |
|
4-Φ14.3 |
10*8.5 |
|
10 0850 31 |
|
-26.6 |
|
Φ101.6 |
|
4-Φ15 |
10*8.5 |
|
10 0850 33 |
|
0 |
|
Φ114.3 |
|
5-Φ14.3 |
12*3 |
|
12 0300 03 |
|
-45.2 |
|
Φ136.5 |
|
6-Φ10.5 |
12*3 |
|
12 0300 06 |
|
34 |
|
Φ114.3 |
|
5-Φ13.5 |
12*7 |
|
12 0700 07 |
|
-84.5 |
|
Φ180.1 |
|
8-Φ11.2 |
12*7 |
|
12 0700 08 |
|
10.5 |
|
Φ110 |
|
4-Φ14.8 |
12*7 |
|
12 0700 10 |
|
0 |
|
Φ114.3 |
|
5-Φ13.5 |
12*7 |
|
12 0700 17 |
|
20 |
|
Φ120 |
|
6-Φ11 |
12*7 |
|
12 0700 20 |
|
0 |
|
Φ120 |
|
6-Φ14.3 |
12*7 |
|
12 0700 22 |
|
38 |
|
Φ114.3 |
|
5-Φ14.3 |
12*7 |
|
12 0700 32 |
|
-35.8 |
|
Φ101.6 |
|
4-Φ14.3 |
12*7 |
|
12 0700 33 |
|
0 |
|
Φ101.6 |
|
4-Φ14.3 |
12*7 |
|
12 0700 35 |
|
-31.8 |
|
Φ114.3 |
|
5-Φ12 |
12*7 |
|
12 0700 36 |
|
-19.1 |
|
Φ101.6 |
|
4-Φ14.3 |
12*7 |
|
12 0700 40 |
|
31.2 |
|
Φ114.3 |
|
5-Φ14.3 |
12*7 |
|
12 0700 47 |
|
0 |
|
Φ114.3 |
|
5-Φ14.3 |
12*7 |
|
12 0700 54 |
|
0 |
|
Φ101.6 |
|
4-Φ14.3 |
12*7 |
|
12 0700 55 |
|
-35 |
|
Φ114.3 |
|
5-Φ12 |
12*7 |
|
12 0700 57 |
|
0 |
|
Φ114.3 |
|
5-Φ14.3 |
12*7 |
|
12 0700 62 |
|
-19 |
|
Φ101.6 |
|
4-Φ14.3 |
12*7 |
|
12 0700 64 |
|
-17.6 |
|
Φ130 |
|
4-Φ15 |
12*7 |
|
12 0700 65 |
|
-57.2 |
|
Φ101.6 |
|
4-Φ14.3 |
12*7 |
|
12 0700 66 |
|
-25.4 |
|
Φ101.6 |
|
4-Φ14.3 |
12*7 |
|
12 0700 72 |
|
0 |
|
Φ101.6 |
|
4-Φ14.8 |
12*7 |
|
12070093 |
|
-20 |
|
Φ140 |
|
5-Φ14.8 |
12*7 |
|
12070095 |
|
-56 |
|
Φ114.3 |
|
5-Φ14.3 |
12*7 |
|
12070102 |
|
19.1 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8 |
|
12 0800 03 |
|
16.5 |
|
Φ156 |
|
5-Φ10.5 |
12*8 |
|
12 0800 05 |
|
34.5 |
|
Φ156 |
|
5-Φ10.5 |
12*8 |
|
12 0800 07 |
|
0 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8 |
|
12 0800 15 |
|
-8.5 |
|
Φ114.3 |
|
5-Φ13.5 |
12*8 |
|
12 0800 20 |
|
-15.3 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 01 |
|
10 |
|
Φ114.3 |
|
5-Φ12 |
12*8.5 |
|
12 0850 02 |
|
-32.5 |
|
Φ101.6 |
|
4-Φ14 |
12*8.5 |
|
12 0850 06 |
|
0 |
|
Φ110 |
|
4-Φ14.8 |
12*8.5 |
|
12 0850 08 |
|
-61.5 |
|
Φ114.3 |
|
5-Φ12 |
12*8.5 |
|
12 0850 12 |
|
-44.5 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 13 |
|
-32 |
|
Φ101.6 |
|
4-Φ14.8 |
12*8.5 |
|
12 0850 19 |
|
-40.5 |
|
Φ101.6 |
|
4-Φ14 |
12*8.5 |
|
12 0850 25 |
|
10 |
|
Φ114.3 |
|
5-Φ12 |
12*8.5 |
|
12 0850 27 |
|
0 |
|
Φ140 |
|
5-Φ18.5 |
12*8.5 |
|
12 0850 34 |
|
-20.6 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 35 |
|
44.8 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 36 |
|
17 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 39 |
|
29.2 |
|
Φ152.4 |
|
6-Φ15 |
12*8.5 |
|
12 0850 40 |
|
-5.6 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 47 |
|
-17 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 55 |
|
-26.16 |
|
Φ101.6 |
|
4-Φ14.8 |
12*8.5 |
|
12 0850 56 |
|
0 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 57 |
|
-44.45 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 62 |
|
0 |
|
Φ120 |
|
6-Φ12.5 |
12*8.5 |
|
12 0850 63 |
|
38 |
|
Φ110 |
|
4-Φ16 |
12*8.5 |
|
12 0850 66 |
|
10 |
|
Φ114.3 |
|
5-Φ12 |
12*8.5 |
|
12 0850 69 |
|
-33.3 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 73 |
|
-54.9 |
|
Φ114.3 |
|
5-Φ12 |
12*8.5 |
|
12 0850 76 |
|
0 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 78 |
|
-3.2 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 81 |
|
-40.6 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 82 |
|
0 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 83 |
|
-66 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 0850 85 |
|
31.8 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 86 |
|
46.2 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 91 |
|
-28.6 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 0850 98 |
|
34.9 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 085 100 |
|
56.8 |
|
Φ140 |
|
5-Φ14.7 |
12*8.5 |
|
12 085 101 |
|
37.3 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 085 102 |
|
-44.5 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 085 105 |
|
-56 |
|
Φ114.3 |
|
5-Φ14.3 |
12*8.5 |
|
12 085 108 |
|
-34.9 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 085 109 |
|
-34.3 |
|
Φ114.3 |
|
5-Φ13.5 |
12*8.5 |
|
12 085 111 |
|
-25.4 |
|
Φ101.6 |
|
4-Φ14.3 |
12*8.5 |
|
12 085 116 |
|
-9.5 |
|
Φ114.3 |
|
5-Φ12 |
12*8.5 |
|
12 085 117 |
|
65.1 |
|
Φ152.4 |
|
5-Φ14 |
12*8.5 |
|
12 085 128 |
|
-57.15 |
|
Φ101.6 |
|
4-Φ14.3 |
12*9.5 |
|
12 0950 03 |
|
-19 |
|
Φ152.4 |
|
6-Φ15 |
12*9.5 |
|
12 0950 12 |
|
18.3 |
|
Φ114.3 |
|
5-Φ14.3 |
12*9.5 |
|
12 0950 13 |
|
-46.7 |
|
Φ101.6 |
|
4-Φ14.3 |
12*10.5 |
|
12 1050 01 |
|
-34 |
|
Φ114.3 |
|
5-Φ12 |
12*10.5 |
|
12 1050 02 |
|
0 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 03 |
|
-25.4 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 04 |
|
-5 |
|
Φ114.3 |
|
5-Φ12 |
12*10.5 |
|
12 1050 05 |
|
3.3 |
|
Φ152.4 |
|
6-Φ15 |
12*10.5 |
|
12 1050 06 |
|
-25.4 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 07 |
|
-49.2 |
|
Φ114.3 |
|
5-Φ12 |
12*10.5 |
|
12 1050 09 |
|
-25.4 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 10 |
|
31.75 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 14 |
|
-57.15 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 15 |
|
57.2 |
|
Φ140 |
|
5-Φ18.5 |
12*10.5 |
|
12 1050 16 |
|
-22.2 |
|
Φ140 |
|
5-Φ18.5 |
12*10.5 |
|
12 1050 21 |
|
101.4 |
|
Φ152.4 |
|
6-Φ15 |
12*10.5 |
|
12 1050 27 |
|
-27.4 |
|
Φ114.3 |
|
5-Φ12 |
12*10.5 |
|
12 1050 31 |
|
-5 |
|
Φ140 |
|
5-Φ18.5 |
12*10.5 |
|
12 1050 32 |
|
-46.5 |
|
Φ203.2 |
|
8-Φ15 |
12*10.5 |
|
12 1050 33 |
|
-26.2 |
|
Φ101.6 |
|
4-Φ14.8 |
12*10.5 |
|
12 1050 36 |
|
-57.2 |
|
Φ114.3 |
|
5-Φ14.3 |
12*10.5 |
|
12 1050 37 |
|
-23 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 38 |
|
-40 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 45 |
|
-20.8 |
|
Φ114.3 |
|
5-Φ14.3 |
12*10.5 |
|
12 1050 49 |
|
12.3 |
|
Φ110 |
|
4-Φ16 |
12*10.5 |
|
12 1050 50 |
|
-25.4 |
|
Φ114.3 |
|
5-Φ14.8 |
12*10.5 |
|
12 1050 51 |
|
14.6 |
|
Φ140 |
|
5-Φ18.5 |
12*10.5 |
|
12 1050 57 |
|
6.4 |
|
Φ114.3 |
|
5-Φ14.3 |
12*10.5 |
|
12 1050 58 |
|
-0.76 |
|
Φ101.6 |
|
4-Φ14.8 |
12*10.5 |
|
12 1050 59 |
|
33.7 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 60 |
|
0 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 63 |
|
-59.7 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 66 |
|
-6.4 |
|
Φ114.3 |
|
5-Φ14.3 |
12*10.5 |
|
12 1050 71 |
|
-50.8 |
|
Φ152.4 |
|
6-Φ15 |
12*10.5 |
|
12 1050 73 |
|
44 |
|
Φ152.4 |
|
6-Φ15 |
12*10.5 |
|
12 1050 74 |
|
-54.9 |
|
Φ203.2 |
|
8-Φ15 |
12*10.5 |
|
12 1050 78 |
|
-23 |
|
Φ114.3 |
|
5-Φ13.5 |
13*4.5 |
|
13 0450 02 |
|
11 |
|
Φ115 |
|
4-Φ13.8 |
14*7 |
|
14 0700 04 |
|
3.1 |
|
Φ101.6 |
|
4-Φ13.5 |
14*8 |
|
14 0800 01 |
|
-3.9 |
|
Φ101.6 |
|
4-Φ13.5 |
14*8 |
|
14 0800 12 |
|
-3.9 |
|
Φ101.6 |
|
4-Φ16 |
14*8 |
|
14 0800 17 |
|
10.2 |
|
Φ114.3 |
|
5-Φ12 |
14*10.5 |
|
14 1050 02 |
|
-16.1 |
|
Φ114.3 |
|
5-Φ12 |
14*10.5 |
|
14 1050 03 |
|
-32.1 |
|
Φ101.6 |
|
4-Φ13.5 |
8*7 |
|
08 0700 65 |
|
-65.9 |
|
Φ101.6 |
|
4-Φ15 |
大農機系列
新型鋁輪系列
大農機系列
新型鋁輪系列
風馳官方微信
Copyright ? 2023 浙江風馳機械 All Rights Reserved. 浙ICP備17009245號-1 浙公網安備 33108102000783號 技術支持:臺州黑石網絡
