規格 |
|
產品編號 |
|
芯子長度 |
|
軸套內徑 | |
3*2 |
|
03 0200 01 |
|
76.2 |
|
Φ35 | |
3*2 |
|
03 0200 02 |
|
69.8 |
|
Φ35 | |
4*2.25 |
|
04 0225 04 |
|
95.2 |
|
Φ35 | |
4*2.25 |
|
04 0225 06 |
|
104.7 |
|
Φ42 | |
4*2.42 |
|
040242 02 |
|
51.2 |
|
Φ35 | |
4*2.5 |
|
04 0250 02 |
|
76.2 |
|
Φ35 | |
4*2.5 |
|
04 0250 05 |
|
74.5 |
|
Φ35 | |
4*2.5 |
|
04 0250 10 |
|
66.7 |
|
Φ35 | |
4*2.5 |
|
04 0250 11 |
|
76.7 |
|
Φ35 | |
4*2.5 |
|
04 0250 13 |
|
109.2 |
|
Φ35 | |
5*2.5 |
|
05 0250 01 |
|
108 |
|
Φ35 | |
5*3 |
|
05 0300 03 |
|
111 |
|
Φ35 | |
5*3 |
|
05 0300 04 |
|
88 |
|
Φ52 | |
5*3 |
|
05 0300 10 |
|
107.5 |
|
Φ35 | |
5*3 |
|
05 0300 12 |
|
100.8 |
|
Φ35 | |
5*3 |
|
05 0300 14 |
|
114.3 |
|
Φ35 | |
5*3 |
|
05 0300 15 |
|
114.3 |
|
Φ45.2 | |
5*3 |
|
05 0300 16 |
|
93.6 |
|
Φ52 | |
5*3 |
|
05 0300 18 |
|
120.1 |
|
Φ35 | |
5*3 |
|
05 0300 19 |
|
121.6 |
|
Φ35 | |
5*3 |
|
05 0300 20 |
|
107.8 |
|
Φ35 | |
5*3 |
|
05 0300 23 |
|
120.1 |
|
Φ35 | |
5*3 |
|
05 0300 24 |
|
111 |
|
Φ45.2 | |
5*3 |
|
05 0300 26 |
|
111 |
|
Φ44.5 | |
5*3 |
|
05 0300 27 |
|
142.9 |
|
Φ35 | |
5*3.25 |
|
05 0325 02 |
|
117.4 |
|
Φ35 | |
5*3.25 |
|
05 0325 03 |
|
115.7 |
|
Φ45.2 | |
5*3.25 |
|
05 0325 04 |
|
114.3 |
|
Φ45.2 | |
6*3.25 |
|
06 0325 03 |
|
117.5 |
|
Φ25.68 | |
6*3.25 |
|
06 0325 06 |
|
119.6 |
|
Φ35 | |
6*3.25 |
|
06 0325 26 |
|
146.05 |
|
Φ35 | |
6*3.25 |
|
06 0325 34 |
|
101.6 |
|
Φ45.2 | |
6*3.25 |
|
06 0325 35 |
|
87.8 |
|
Φ35 | |
6*3.25 |
|
06 0325 42 |
|
101 |
|
Φ26 | |
6*3.25 |
|
06 0325 50 |
|
145.1 |
|
Φ44.5 | |
6*3.25 |
|
06 0325 53 |
|
137.5 |
|
Φ35 | |
6*3.25 |
|
06 0325 55 |
|
142.9 |
|
Φ45.2 | |
6*3.5 |
|
06 0350 01 |
|
145.6 |
|
Φ45.2 | |
6*3.5 |
|
06 0350 05 |
|
126.4 |
|
Φ52 | |
6*3.5 |
|
06 0350 07 |
|
155.5 |
|
Φ50.8 | |
6*3.5 |
|
06 0350 08 |
|
51.5 |
|
Φ52 | |
6*3.5 |
|
06 0350 14 |
|
108.4 |
|
Φ35 | |
6*3.5 |
|
06 0350 15 |
|
146.9 |
|
Φ35 | |
6*3.5 |
|
06 0350 18 |
|
145.6 |
|
Φ45.2 | |
6*3.5 |
|
06 0350 21 |
|
69 |
|
Φ45.2 | |
6*3.5 |
|
06 0350 23 |
|
142.9 |
|
Φ45.2 | |
6*3.5 |
|
06 0350 26 |
|
69.2 |
|
Φ35 | |
6*3.5 |
|
06 0350 28 |
|
145.6 |
|
Φ45.2 | |
6*3.5 |
|
06 0350 33 |
|
142.9 |
|
Φ45.2 | |
6*3.5 |
|
06 0350 35 |
|
127.8 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 01 |
|
165 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 06 |
|
76 |
|
Φ44.5 | |
6*4.5 |
|
06 0450 07 |
|
100 |
|
Φ52 | |
6*4.5 |
|
06 0450 08 |
|
83 |
|
Φ35 | |
6*4.5 |
|
06 0450 11 |
|
171.4 |
|
Φ52 | |
6*4.5 |
|
06 0450 13 |
|
170.5 |
|
Φ52 | |
6*4.5 |
|
06 0450 15 |
|
197.56 |
|
Φ50.8 | |
6*4.5 |
|
06 0450 16 |
|
87 |
|
Φ19.2 | |
6*4.5 |
|
06 0450 17 |
|
158.75 |
|
Φ25.57 | |
6*4.5 |
|
06 0450 18 |
|
170 |
|
Φ35 | |
6*4.5 |
|
06 0450 20 |
|
69.4 |
|
Φ44.5 | |
6*4.5 |
|
06 0450 26 |
|
178.8 |
|
Φ44.5 | |
6*4.5 |
|
06 0450 32 |
|
148.6 |
|
Φ35 | |
6*4.5 |
|
06 0450 33 |
|
70.6 |
|
Φ35 | |
6*4.5 |
|
06 0450 35 |
|
91 |
|
Φ35 | |
6*4.5 |
|
06 0450 36 |
|
68 |
|
Φ35 | |
6*4.5 |
|
06 0450 38 |
|
78 |
|
Φ35 | |
6*4.5 |
|
06 0450 44 |
|
166.8 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 46 |
|
66.7 |
|
Φ35 | |
6*4.5 |
|
06 0450 49 |
|
166 |
|
Φ35 | |
6*4.5 |
|
06 0450 53 |
|
88.9 |
|
Φ52 | |
6*4.5 |
|
06 0450 54 |
|
184.2 |
|
Φ35 | |
6*4.5 |
|
06 0450 56 |
|
177.1 |
|
Φ35 | |
6*4.5 |
|
06 0450 57 |
|
181 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 60 |
|
177.1 |
|
Φ35 | |
6*4.5 |
|
06 0450 63 |
|
184.2 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 64 |
|
165 |
|
Φ35 | |
6*4.5 |
|
06 0450 65 |
|
88 |
|
Φ52 | |
6*4.5 |
|
06 0450 74 |
|
177.8 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 75 |
|
69.9 |
|
Φ25.57 | |
6*4.5 |
|
06 0450 77 |
|
170.2 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 81 |
|
62 |
|
Φ35 | |
6*4.5 |
|
06 0450 83 |
|
166.8 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 84 |
|
175.3 |
|
Φ35 | |
6*4.5 |
|
06 0450 88 |
|
177.1 |
|
Φ35 | |
6*4.5 |
|
06 0450 89 |
|
171.5 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 92 |
|
174.6 |
|
Φ35 | |
6*4.5 |
|
06 0450 96 |
|
184.2 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 97 |
|
166.6 |
|
Φ45.2 | |
6*4.5 |
|
06 0450 98 |
|
170.2 |
|
Φ85.1 | |
6*4.5 |
|
06 045 100 |
|
78 |
|
Φ35 | |
6*4.5 |
|
06 045 105 |
|
170.9 |
|
Φ35 | |
8*2.5 |
|
08 0250 07 |
|
77.5 |
|
Φ35 | |
8*2.5 |
|
08 0250 09 |
|
92.4 |
|
Φ35 | |
8*3.75 |
|
08 0375 05 |
|
80 |
|
Φ52 | |
8*3.75 |
|
08 0375 10 |
|
104.8 |
|
Φ50.2 | |
8*3.75 |
|
08 0375 12 |
|
133.4 |
|
Φ25.68 | |
8*3.75 |
|
08 0375 19 |
|
70 |
|
Φ35 | |
8*3.75 |
|
08 0375 20 |
|
130.5 |
|
Φ45.2 | |
8*3.75 |
|
08 0375 22 |
|
104.8 |
|
Φ50.2 | |
8*4.5 |
|
08 0450 01 |
|
166.8 |
|
Φ45.2 | |
8*5.375 |
|
08 0538 03 |
|
75.6 |
|
Φ52 | |
8*5.375 |
|
08 0538 06 |
|
100 |
|
Φ52 | |
8*5.375 |
|
08 0538 12 |
|
95 |
|
Φ52 | |
8*5.375 |
|
08 0538 14 |
|
82 |
|
Φ50.8 | |
8*5.375 |
|
08 0538 16 |
|
75.6 |
|
Φ52 | |
8*5.375 |
|
08 0538 20 |
|
69.8 |
|
Φ35 | |
8*5.375 |
|
08 0538 23 |
|
133.4 |
|
Φ25.68 | |
8*5.375 |
|
08 0538 25 |
|
82.6 |
|
Φ52 | |
8*5.375 |
|
08 0538 34 |
|
70.6 |
|
Φ35 | |
8*5.375 |
|
08 0538 38 |
|
72 |
|
Φ52 | |
8*5.375 |
|
08 0538 46 |
|
171 |
|
Φ35 | |
8*5.375 |
|
08 0538 47 |
|
88.9 |
|
Φ52 | |
8*5.375 |
|
08 0538 50 |
|
175.3 |
|
Φ35 | |
8*5.375 |
|
08 0538 51 |
|
82 |
|
Φ52 | |
8*5.375 |
|
08 0538 53 |
|
88.9 |
|
Φ19.25 | |
8*5.375 |
|
08 0538 64 |
|
75 |
|
Φ35 | |
8*6.188 |
|
08 0620 01 |
|
81 |
|
Φ49 | |
8*6.375 |
|
08 0638 01 |
|
89 |
|
Φ25.57 | |
8*6.188 |
|
08 0620 01 |
|
81.2 |
|
Φ52 | |
8*6.38 |
|
08 0638 01 |
|
88.5 |
|
Φ25.57 | |
8*7 |
|
08 0700 08 |
|
247.2 |
|
Φ35 | |
8*7 |
|
08 0700 11 |
|
100 |
|
Φ52 | |
8*7 |
|
08 0700 12 |
|
106 |
|
Φ19.2 | |
8*7 |
|
08 0700 14 |
|
106 |
|
Φ19.2 | |
8*7 |
|
08 0700 15 |
|
88.3 |
|
Φ19.23 | |
8*7 |
|
08 0700 16 |
|
88.9 |
|
Φ52 | |
8*7 |
|
08 0700 17 |
|
95 |
|
Φ52 | |
8*7 |
|
08 0700 18 |
|
88.3 |
|
Φ19.23 | |
8*7 |
|
08 0700 20 |
|
88.3 |
|
Φ19.23 | |
8*7 |
|
08 0700 21 |
|
96.4 |
|
Φ25.57 | |
8*7 |
|
08 0700 23 |
|
75.6 |
|
Φ50.8 | |
8*7 |
|
08 0700 24 |
|
77.3 |
|
Φ50.8 | |
8*7 |
|
08 0700 29 |
|
81.2 |
|
Φ50.8 | |
8*7 |
|
08 0700 35 |
|
85.5 |
|
Φ19.23 | |
8*7 |
|
08 0700 36 |
|
82.6 |
|
Φ52 | |
8*7 |
|
08 0700 45 |
|
65 |
|
Φ52 | |
8*7 |
|
08 0700 48 |
|
131.8 |
|
Φ25.57 | |
10*3.5 |
|
10 0350 01 |
|
74 |
|
Φ52 | |
10*7 |
|
10 0700 19 |
|
120.6 |
|
Φ19.23 | |
10*8.5 |
|
10 0850 05 |
|
97 |
|
Φ25.57 | |
12*7.5 |
|
12 0750 04 |
|
88.3 |
|
Φ19.23 | |
12*7.5 |
|
12 0750 18 |
|
120.6 |
|
Φ19.23 |
規格 |
|
產品編號 |
|
偏距 |
|
中心孔 |
|
分布圓 |
|
螺栓孔 |
6*3.25 |
|
06 0325 44 |
|
-2 |
|
Φ64 |
|
Φ88.9 |
|
3-Φ11 |
6*4.5 |
|
06 0450 03 |
|
0 |
|
Φ55 |
|
Φ79 |
|
3-Φ8.5 |
6*4.5 |
|
06 0450 27 |
|
0 |
|
Φ51.4 |
|
Φ71.8 |
|
4-Φ10.3 |
6*4.5 |
|
06 0450 72 |
|
0 |
|
Φ70 |
|
Φ89 |
|
3-Φ8.5 |
8*2.5 |
|
08 0250 01 |
|
-2 |
|
Φ60 |
|
Φ100 |
|
4-Φ13.5 |
8*4.375 |
|
08 0438 01 |
|
2 |
|
Φ62 |
|
Φ100 |
|
3-Φ11.5 |
8*5.375 |
|
08 0538 01 |
|
2 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
8*5.375 |
|
08 0538 02 |
|
-2 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
8*5.375 |
|
08 0538 04 |
|
-2 |
|
Φ72 |
|
Φ114.3 |
|
5-Φ15 |
8*5.375 |
|
08 0538 05 |
|
18.6 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ13.5 |
8*5.375 |
|
08 0538 07 |
|
-2 |
|
Φ62 |
|
Φ100 |
|
3-Φ11.5 |
8*5.375 |
|
08 0538 18 |
|
-22.6 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
8*5.375 |
|
08 0538 31 |
|
18.6 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
8*5.375 |
|
08 0538 40 |
|
22.6 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ13.5 |
8*5.375 |
|
08 0538 59 |
|
-22.6 |
|
Φ72 |
|
Φ114.3 |
|
5-Φ15 |
8*5.375 |
|
08 0538 63 |
|
18.65 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
8*6.188 |
|
08 0620 02 |
|
-33 |
|
Φ72 |
|
Φ114.3 |
|
5-Φ15 |
8*6.188 |
|
08 0620 04 |
|
-33 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
8*6.188 |
|
08 0620 08 |
|
-33 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
8*7 |
|
08 0700 05 |
|
-23 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
8*7 |
|
08 0700 25 |
|
28.2 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
8*7 |
|
08 0700 26 |
|
-2 |
|
Φ60 |
|
Φ100 |
|
4-Φ13.5 |
8*7 |
|
08 0700 27 |
|
-2 |
|
Φ67 |
|
Φ101.6 |
|
4-Φ12 |
8*7 |
|
08 0700 28 |
|
-23 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
8*7 |
|
08 0700 38 |
|
-2.5 |
|
Φ71.8 |
|
Φ101.6 |
|
4-Φ14.3 |
8*7 |
|
08 0700 42 |
|
-2 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
8*7 |
|
08 0700 44 |
|
-23 |
|
Φ60 |
|
Φ100 |
|
4-Φ13.5 |
8*7 |
|
08 0700 55 |
|
-2 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
8*7 |
|
08 0700 57 |
|
-2 |
|
Φ60 |
|
Φ100 |
|
4-Φ13.5 |
8*7 |
|
08 0700 64 |
|
-2 |
|
Φ75 |
|
Φ114.3 |
|
5-Φ15 |
9*10 |
|
09 1000 01 |
|
-2.5 |
|
Φ79.5 |
|
Φ114.3 |
|
5-Φ12.7 |
9*10 |
|
09 1000 02 |
|
-2.5 |
|
Φ60 |
|
Φ100 |
|
4-Φ13.5 |
9*10 |
|
09 1000 04 |
|
-3 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
9*10 |
|
09 1000 05 |
|
-2.5 |
|
Φ67 |
|
Φ101.6 |
|
4-Φ12.5 |
10*3.5 |
|
10 0350 11 |
|
-2.5 |
|
Φ60 |
|
Φ101.6 |
|
4-Φ13.5 |
10*5.5 |
|
10 0550 02 |
|
16.6 |
|
Φ72 |
|
Φ114.3 |
|
5-Φ15 |
10*5.5 |
|
10 0550 04 |
|
26.25 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
10*6 |
|
10 0600 01 |
|
-5.5 |
|
Φ72 |
|
Φ114.3 |
|
5-Φ15 |
10*6 |
|
10 0600 02 |
|
-5.5 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
10*6 |
|
10 0600 05 |
|
-5.5 |
|
Φ71.8 |
|
Φ101.6 |
|
4-Φ15 |
10*6 |
|
10 0600 08 |
|
-2.3 |
|
Φ70 |
|
Φ100 |
|
3-Φ13.5 |
10*6 |
|
10 0600 22 |
|
-5.5 |
|
Φ94 |
|
Φ140 |
|
5-Φ18.5 |
10*6 |
|
10060075 |
|
-4.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ14.3 |
10*7 |
|
10 0700 01 |
|
-2.3 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
10*7 |
|
10 0700 02 |
|
6.7 |
|
Φ75 |
|
Φ114.3 |
|
5-Φ14.2 |
10*7 |
|
10 0700 03 |
|
-2.5 |
|
Φ79.5 |
|
Φ114.3 |
|
5-Φ12 |
10*7 |
|
10 0700 04 |
|
-28.45 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
10*7.75 |
|
10 0775 03 |
|
-11.5 |
|
Φ72 |
|
Φ101.6 |
|
4-Φ15 |
10*8.5 |
|
10 0850 06 |
|
-21.6 |
|
Φ71.8 |
|
Φ114.3 |
|
5-Φ14.8 |
10*8.5 |
|
10 0850 07 |
|
-2.5 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
10*8.5 |
|
10 0850 10 |
|
-2.5 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ18.2 |
10*8.5 |
|
10 0850 12 |
|
-31.3 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
10*8.5 |
|
10 0850 21 |
|
-34.2 |
|
Φ71.8 |
|
Φ114.3 |
|
5-Φ15 |
