規格 |
|
產品編號 |
|
偏距 |
|
中心孔 |
|
分布圓 |
|
螺栓孔 |
8*5.375 |
|
08 0538 49 |
|
59.75 |
|
Φ74 |
|
Φ94 |
|
4-Φ11 |
10*3 |
|
10 0300 01 |
|
-40.5 |
|
Φ50 |
|
Φ75(Φ85) |
|
4-Φ11(4-Φ13) |
10*3 |
|
10 0300 02 |
|
23.5 |
|
Φ50 |
|
Φ75 |
|
4-Φ11 |
10*3 |
|
10 0300 03 |
|
0 |
|
Φ66 |
|
Φ101.6 |
|
4-Φ11.6 |
10*3.5 |
|
10 0350 08 |
|
-70 |
|
Φ74 |
|
Φ94 |
|
4-Φ11 |
10*5.375 |
|
10 0538 01 |
|
11.85 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
10*6 |
|
10 0600 12 |
|
22.65 |
|
Φ70 |
|
Φ100 |
|
4-Φ13 |
10*6 |
|
10 0600 20 |
|
-4.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ14.3 |
10*6 |
|
10 0600 75 |
|
-4.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ14.3 |
10*8 |
|
10 0800 03 |
|
-18.5 |
|
Φ79.5 |
|
Φ114.3 |
|
5-Φ12 |
10*8 |
|
10 0800 08 |
|
-18.5 |
|
Φ80 |
|
Φ120 |
|
6-Φ11 |
10*8 |
|
10 0800 11 |
|
-25 |
|
Φ80 |
|
Φ120 |
|
6-Φ13 |
10*8 |
|
10 0800 12 |
|
-53 |
|
Φ101.8 |
|
Φ139.7 |
|
5-Φ13 |
10*8 |
|
10 0800 14 |
|
53 |
|
Φ80 |
|
Φ110 |
|
4-Φ11 |
10*8.5 |
|
10 0850 28 |
|
-2.5 |
|
Φ80 |
|
Φ120 |
|
6-Φ13 |
10*11.15 |
|
10 1115 01 |
|
2.5 |
|
Φ64 |
|
Φ101.6 |
|
4-Φ15 |
12*3.75 |
|
12 0375 01 |
|
-4 |
|
Φ85.9 |
|
Φ114.3 |
|
5-Φ13.2 |
12*3.75 |
|
12 0375 02 |
|
-3.5 |
|
Φ85.9 |
|
Φ114.3 |
|
5-Φ13.2 |
12*4 |
|
12 0400 04 |
|
32 |
|
Φ60 |
|
Φ114.3 |
|
4-Φ12.5 |
12*4 |
|
12 0400 07 |
|
30 |
|
Φ80 |
|
Φ120 |
|
6-Φ11 |
12*4 |
|
12 0400 08 |
|
10 |
|
Φ90 |
|
Φ120 |
|
6-Φ12.5 |
12*4 |
|
12 0400 09 |
|
30 |
|
Φ90 |
|
Φ120 |
|
6-Φ13 |
12*5 |
|
12 0500 01 |
|
-57 |
|
Φ50 |
|
Φ85 |
|
4-Φ13 |
12*5 |
|
12 0500 05 |
|
10 |
|
Φ90 |
|
Φ120 |
|
6-Φ13 |
12*5 |
|
12 0500 08 |
|
-54 |
|
Φ74 |
|
Φ94 |
|
4-Φ11 |
12*5 |
|
12 0500 10 |
|
20 |
|
Φ80 |
|
Φ120 |
|
6-Φ11 |
12*7 |
|
12070101 |
|
0 |
|
Φ100.5 |
|
Φ140 |
|
6-Φ19 |
12*10.5 |
|
12 1050 26 |
|
-19 |
|
Φ66.5 |
|
Φ112 |
|
5-Φ19.5 |
12*10.5 |
|
12 1050 28 |
|
0 |
|
Φ79.5 |
|
Φ114.3 |
|
5-Φ13.5 |
12*10.5 |
|
12 1050 40 |
|
0 |
|
Φ93 |
|
Φ140 |
|
6-Φ13 |
12*10.5 |
|
12 1050 47 |
|
58 |
|
Φ79.5 |
|
Φ114.3 |
|
5-Φ13.5 |
13*9.45 |
|
13 0945 01 |
|
6 |
|
Φ134.8 |
|
Φ170 |
|
8-Φ17.9 |
14*5 |
|
14 0500 01 |
|
15 |
|
Φ80 |
|
Φ120 |
|
6-Φ11 |
14*5 |
|
14 0500 02 |
|
80 |
|
Φ80 |
|
Φ120 |
|
6-Φ13 |
14*7 |
|
14 0700 01 |
|
10 |
|
Φ90 |
|
Φ120 |
|
6-Φ13 |
14*7 |
|
14 0700 03 |
|
22.9 |
|
Φ90 |
|
Φ150 |
|
6-Φ15 |
14*8 |
|
14 0800 03 |
|
57.1 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15.8 |
14*8 |
|
14 0800 28 |
|
30 |
|
Φ112 |
|
Φ160 |
|
5-Φ17 |
15*8 |
|
15 0800 01 |
|
28.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*8 |
|
15 0800 02 |
|
50 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*8 |
|
15 0800 05 |
|
28.5 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17.5 |
15*8 |
|
15 0800 09 |
|
28.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*8 |
|
15 0800 10 |
|
0 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*10 |
|
15 1000 01 |
|
-15.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*10 |
|
15 1000 03 |
|
12.7 |
|
Φ93 |
|
Φ140 |
|
5-Φ14.9 |
15*10 |
|
15 1000 07 |
|
-66.7 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17.5 |
15*10 |
|
15 1000 13 |
|
-28.7 |
|
Φ203.2 |
|
Φ241.3 |
|
9-Φ17.5 |
15*10 |
|
15 1000 14 |
|
10.9 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*10 |
|
15 1000 15 |
|
-15.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*10 |
|
15 1000 16 |
|
1.1 |
|
Φ201.6 |
|
Φ241.3 |
|
9-Φ14.3 |
15*10 |
|
15 1000 21 |
|
-12.7 |
|
Φ160.5 |
|
Φ180 |
|
8-Φ10.7 |
15*10 |
|
15 1000 29 |
|
-30.2 |
|
Φ93 |
|
Φ140 |
|
5-Φ14.7 |
15*10 |
|
15 1000 30 |
|
20.6 |
|
Φ93 |
|
Φ140 |
|
5-Φ14.7 |
15*10 |
|
15 1000 33 |
|
28.5 |
|
Φ17.5 |
|
Φ152.4 |
|
6-Φ15 |
15*10 |
|
15 1000 34 |
|
28.5 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*10 |
|
15 1000 35 |
|
28.5 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17.5 |
15*12 |
|
15 1200 01 |
|
-57 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17.5 |
15*12 |
|
15 1200 02 |
|
12.7 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
15*13 |
|
15 1300 01 |
|
-10 |
|
Φ93 |
|
Φ140 |
|
10-Φ17.5 |
15*13 |
|
15 1300 03 |
|
-5 |
|
Φ100 |
|
Φ135 |
|
11-Φ18.5 |
15*13 |
|
15 1300 04 |
|
-36.5 |
|
Φ100 |
|
Φ135 |
|
11-Φ18.5 |
15*13 |
|
15 1300 05 |
|
-37.1 |
|
Φ50 |
|
Φ120 |
|
6-Φ12.5 |
15*13 |
|
15 1300 07 |
|
-20.6 |
|
Φ93 |
|
Φ140 |
|
10-Φ14.8 |
15*13 |
|
15 1300 08 |
|
-57.1 |
|
Φ120 |
|
Φ150 |
|
6-Φ13.5 |
15*13 |
|
15 1300 09 |
|
-37.1 |
|
Φ50 |
|
Φ120 |
|
6-Φ14.5 |
15*13 |
|
15 1300 12 |
|
30.3 |
|
Φ93.2 |
|
Φ140 |
|
10-Φ17.5 |
16*5 |
|
16 0500 01 |
|
35 |
|
Φ117.4 |
|
Φ152.4 |
|
6-Φ15 |
16*5 |
|
16 0500 02 |
|
66 |
|
Φ117.4 |
|
Φ152.4 |
|
6-Φ15 |
16*5 |
|
16 0500 03 |
|
-33 |
|
Φ117.4 |
|
Φ152.4 |
|
6-Φ15 |
16*5 |
|
16 0500 05 |
|
39.7 |
|
Φ115.5 |
|
Φ165 |
|
5-Φ18.5 |
16*5 |
|
16 0500 07 |
|
-42 |
|
Φ70 |
|
Φ115 |
|
4-Φ15 |
16*5 |
|
16 0500 08 |
|
30 |
|
Φ110 |
|
Φ150 |
|
6-Φ13 |
16*5 |
|
16 0500 10 |
|
35 |
|
Φ152 |
|
Φ203.2 |
|
8-Φ17.5 |
16*5 |
|
16 0500 12 |
|
-19 |
|
Φ110 |
|
Φ150 |
|
6-Φ13 |
16*10.5 |
|
16 1050 02 |
|
-54 |
|
Φ79.5 |
|
Φ114.3 |
|
5-Φ13.5 |
16.5*8.25 |
|
165 825 05 |
|
-33.5 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17 |
16.5*8.25 |
|
165 825 06 |
|
9.7 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17 |
16.5*8.25 |
|
165 825 09 |
|
5 |
|
Φ117.4 |
|
Φ152.4 |
|
6-Φ16.7 |
16.5*8.25 |
|
165 825 10 |
|
74.7 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17 |
16.5*8.25 |
|
165 825 11 |
|
28.4 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17 |
16.5*9.75 |
|
165 975 05 |
|
50 |
|
Φ221.5 |
|
Φ275 |
|
8-Φ20 |
16.5*9.75 |
|
165 975 06 |
|
-42.8 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17 |
16.5*9.75 |
|
165 975 08 |
|
27 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17 |
16.5*9.75 |
|
165 975 09 |
|
84.1 |
|
Φ152.4 |
|
Φ203.2 |
|
8-Φ17 |
16.5*9.75 |
|
165 975 13 |
|
20 |
|
Φ94 |
|
Φ140 |
|
5-Φ18.5 |
17.5*10.5 |
|
175 105 01 |
|
7.9 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ12.7 |
17.5*10.5 |
|
175 105 03 |
|
28.4 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
18*6 |
|
18 0600 01 |
|
42 |
|
Φ90 |
|
Φ150 |
|
6-Φ15 |
18*6 |
|
18 0600 02 |
|
20 |
|
Φ114.5 |
|
Φ152 |
|
6-Φ15 |
18*6 |
|
18 0600 03 |
|
0 |
|
Φ101.6 |
|
Φ139.7 |
|
5-Φ13.5 |
18*6 |
|
18 0600 05 |
|
27.8 |
|
Φ117.4 |
|
Φ152.4 |
|
6-Φ15 |
18*6 |
|
18 0600 06 |
|
30 |
|
Φ117.4 |
|
Φ152.4 |
|
6-Φ15 |
18*6 |
|
18 0600 08 |
|
-3.5 |
|
Φ104.2 |
|
Φ139.7 |
|
10-Φ13 |
18*6 |
|
18 0600 10 |
|
60 |
|
Φ13.5 |
|
Φ170 |
|
6-Φ17 |
19.5*11.75 |
|
195 118 01 |
|
-66.1 |
|
Φ135.2 |
|
Φ170 |
|
6-Φ17 |
20*6 |
|
20 0600 01 |
|
42 |
|
Φ90 |
|
Φ120 |
|
6-Φ15 |
20*7 |
|
20 0700 01 |
|
20 |
|
Φ114.5 |
|
Φ152 |
|
6-Φ15 |
20*7 |
|
20 0700 02 |
|
12 |
|
Φ90 |
|
Φ120 |
|
6-Φ15 |
20*11 |
|
20 1100 04 |
|
-56.4 |
|
Φ201.6 |
|
Φ241.3 |
|
9-Φ17.5 |
20*11 |
|
20 1100 05 |
|
42 |
|
Φ152.5 |
|
Φ203.2 |
|
8-Φ17.5 |
20*11 |
|
20 1100 06 |
|
0 |
|
Φ201.6 |
|
Φ241.3 |
|
9-Φ17.5 |
20*11 |
|
20 1100 12 |
|
-39 |
|
Φ161 |
|
Φ205 |
|
6-Φ17 |
22*7 |
|
22 0700 01 |
|
27 |
|
Φ90 |
|
Φ120 |
|
6-Φ15 |
22*7 |
|
22 0700 02 |
|
12 |
|
Φ90 |
|
Φ120 |
|
6-Φ15 |
24*9 |
|
24 0900 01 |
|
40 |
|
Φ135 |
|
Φ170 |
|
6-Φ17 |
24*9 |
|
24 0900 02 |
|
16.2 |
|
Φ117.5 |
|
Φ152.4 |
|
6-Φ15 |
24*10 |
|
24 1000 02 |
|
-89 |
|
Φ152.5 |
|
Φ203.2 |
|
8-Φ17.5 |
24*10 |
|
24 1000 03 |
|
21.5 |
|
Φ161 |
|
Φ205 |
|
6-Φ17 |
24*10 |
|
24 1000 05 |
|
-91 |
|
Φ152.5 |
|
Φ203.2 |
|
8-Φ20 |
24*10 |
|
24 1000 09 |
|
67 |
|
Φ135 |
|
Φ170 |
|
6-Φ17 |
24*12 |
|
24 1200 01 |
|
-30.2 |
|
Φ152.5 |
|
Φ203.2 |
|
8-Φ17.5 |
24*12 |
|
24 1200 03 |
|
63.5 |
|
Φ135.2 |
|
Φ170 |
|
6-Φ17 |
24*12 |
|
24 1200 04 |
|
-31.5 |
|
Φ161 |
|
Φ205 |
|
6-Φ17 |
24*12 |
|
24 1200 06 |
|
83.9 |
|
Φ135 |
|
Φ170 |
|
6-Φ17 |
26*11 |
|
26 1100 01 |
|
-136 |
|
Φ152.6 |
|
Φ203.2 |
|
8-Φ15 |
26*11 |
|
26 1100 02 |
|
14 |
|
Φ152.5 |
|
Φ203.2 |
|
8-Φ19.5 |
26*11 |
|
26 1100 05 |
|
14 |
|
Φ135 |
|
Φ170 |
|
6-Φ17.5 |
26*11 |
|
26 1100 06 |
|
14 |
|
Φ135 |
|
Φ170 |
|
6-Φ17.5 |
